Fish string automatic rewinding machine (SS-RW02)
Product 3/3  Automatic rewinding machine  Automatic wire spool rewinding machine (SS-RW01)  Plastic string rewinding machine (SS-RW03)
  • Fish string automatic rewinding machine (SS-RW02)
  • Fish string automatic rewinding machine (SS-RW02)
  • Fish string automatic rewinding machine (SS-RW02)
  • Fish string automatic rewinding machine (SS-RW02)

    Product name : Programmable precise automatic string winding machine (SS-RW02)




    Description :

    The (SS-RW02) fish string rewinding machine is one High-Torsion digital coil rewinding machine. It is digital Programmable coil rewinding machine with 1/2HP DC motor. The Maximum wire diameter can reach 3.0mm. It's the best choice for rewinding fiber string, fiber suture, rewinding fish string, rewinding fish wire, rewinding fish thread, rewinding copper wire, rewinding wires, rewinding plastic string, rewinding textile thread, rewinding sewing thread, etc. .This machine can be customized according to coil size by requested

    Feature :

    1. Microprocessor design, easy for program-setting.

    2. Stepper motor driven by constant-current power supply, high spreading Speed precise winding.

    3. "Start Point" could set by key panel or with teachable function. Display Will show the position of spreading head while setting.

    4. Wire passing through ceramic rollers prevent enamel from high temperature.

    5. Two wire spreading heads with winding nozzle make sure the spreading wire precise and be high efficiency.

    6. Foot-switch connection for better efficiency.

    7. Winding parameters and options can be set.

    Specification :

    Model SS-RW02
    Spindle Number1
    Wire diameter0.5~3.0mm
    Spread pitch0~9.999mm
    Spread width(traverse)350mm
    Finished coil diameter200mm
    Winding motor500W DC Motor
    Spread motor4-Phase Stepper Motor
    Max. speed1600 / 400rpm
    Memory999 Steps
    Power sourceAC220V/110V + 10%, 50/60 Hz
    Dimension(cm)70x52x60
    Net weight42kgs
