Big size range amorphous ribbon toroidal core fully automatic welding winding machine(SS-RTC04)
Product 2/13  Automatic toroid coil winding machine  Automatic amorphous ribbon toroid core welding winding machine (SS-RTC01)  Amorphous ribbon toroidal core automatic welding winding machine (SS-RTC series)
  • Big size range amorphous ribbon toroidal core fully automatic welding winding machine(SS-RTC04)
  • Big size range amorphous ribbon toroidal core fully automatic welding winding machine(SS-RTC04)

    Working video


    Production name : Big size range amorphous ribbon toroidal core fully automatic welding winding machine(SS-RTC04)



    Description :

    The big size range amorphous ribbon toroidal core fully automatic welding winding machine (SS-RTC04) adopts precise programmable PLC winding controller. It's an accurately and reliability digital amorphous ribbon toroidal core winding machine with welding function. This nanocrystalline ribbon toroid core winding machine is named amorphous magnetic core making machine, alloy magnetic core winding machine and metal foil toroid core winding machine also. This morphous ribbon toroid core welding winding machine can wind a lot of different size cores through change the different winding models. This toroid core winding machine is used for making the amorphous nanocrystalline crystalline ribbon magnetic toroidal inductor core, amorphous ribbon magnetic toroidal transformer core, amorphous ribbon magnetic toroid chock core, etc. .

    Features :

    1. Adopts precise programmable PLC winding controller.

    2. Integrated the welding function with it. can complete the amorphous ribbon winding and welding at same position.

    3. Load ribbon, winding, welding, cutting and download automatically.

    4. The welding current is adjustable for different thickness ribbon request.

    5. Accurately count turns of winding by high frequency response photo-electricity sensor.

    6. Programmable winding direction.

    7. Accurately speed be programmable.

    8. Saved programs with off-power memory retention.

    Specification :

    Model Ribbon toroid core inner diameter depend on spindle size (mm) Ribbon toroid core out diameter (mm) Ribbon width depend on spindle size (mm) Ribbon thickness (um) Power source (Single phase) Air source Size (cm) and weight (Kg)
    SS-RTC04 50 ~250 60~300 30 ~ 50 15~35 220V,50/60HZ 0.7Mpa L300*120*H160,  450
