    Product name : Single spindle programmable automatic transformer coil winding machine (SS600)






    Description :
    The (SS600) Automatic CNC coil winding machine is one digital programmable coil winding machine, there are insulation tape device and margin tape device with the machine. It's the best choice for winding transformer,relay,inductors, contactor coil,speaker voice coil, valve coil,ignition coil,etc.
    Features:
    1. Spreading head of SS600 can install four type different size wires at the same time.
    2. Winding and taping can be done by one machine.
    3. Step motor driven by constant-current power supply, high
    Spreading speed precise winding.
    4. "Start Point" could set by key panel or with teachable function.
    Display will show the position of spreading head while setting.
    5. Small wire diameter products of spreading by nozzle type spreading head.
    6. Wire passing through ceramic rollers prevent enamel from high temperature.
    7. Foot-switch connection for better efficiency.
    8. Winding parameters and options can be set independently for each step.
    9. Memory capacity accommodates 999 steps of parameters with
    Off-power memory retention.
    Specification:

    Model SS-600
    Spindles 1
    Wire size 0.08~ 1.0mm
    Spread pitch 0~ 9.999mm
    Spread width 100mm (Max. )
    Coil diameter 110mm (Max. )
    Main motor Brushless Motor
    Spread motor 2-Phase Stepper Motor
    MAX. speed 6000rpm
    Memory 999 Steps
    Power source AC220V/110V ±10%, 50/60 Hz
    Dimension(CM) 76x68x72
    Net weight(KG) 37
