The (SS102A) digital coil winding machine adopts digital controller. It's an accurately and reliability digital coil winding machine for winding transformers, inductors, relays, contactor,etc.. It is one very economical. it spreads wire by manual(semi-automatic).

Features :

1. Accurately count turns of winding by photo-electricity sensor.

2. Programmable winding direction,winding turns,pre-stop& pre-start speed. Programmable many steps for many different windings coil.

3. Set brake time for each step.

4. Memory capacity accommodates 99 sequences of parameters with off-power memory retention.

5. Spread wire way : operator hold the copper wire to spread by manual.

6. More convenience by using foot-switch.

7. Easy to use VR-switch to adjust the speed of machine.

Specification :

Model	SS102A
Winding spindle	1
Wire diameter	0.03~2.0mm
Winding motor	300W DC Motor
MAX. speed	5000rpm
Memory	99 Steps
Power source	AC220V/110V +10%,50/60Hz
Dimension (cm)	34x49x34
Net weight(Kg)	15
